First Line highlights Nissan Qashqai I wiper motor issue

February 01, 2022
First Line highlights Nissan Qashqai I wiper motor issue
Share:

Parts specialist First Line Ltd. has once again highlighted some common problems that cause wiper motor failure, which can be especially prevalent at this time of year.


One persistent problem concerns the Renault Clio wiper motor (FWM1004/BWM1004) which fails as a result of being submerged in water due to a blocked drain channel. It is recommended that technicians check this when vehicles come into the workshop, especially during winter months.

Jon Roughley, Global Marketing Director for First Line advises, “To resolve the issue technicians need to not only replace the wiper motor, but during the procedure, must also remember to clear any blockages, check all the drain holes and ensure the mechanism is free of corrosion and moving freely. In addition, proactive workshops would do well to advise the customer to keep an eye on the situation to ensure it is kept free of debris and able to drain properly.”

In many other cars, First Line has also found that the most common cause of the wiper motor failure is because linkages wear, which leads to the ball joints popping off their sockets, bringing the wiper blades to a complete stop. However, with the popular, first generation Nissan Qashqai, there is another big problem to be aware of. Reacting to the high demand for replacement motors for this vehicle, First Line Ltd’s product team investigated the problem and discovered a weakness in the design of the OE product, which results in the output shaft seizing, due to the build-up of rust.

This is caused because the output shaft is neither sealed nor lubricated and due to its location, following heavy rainfall, water is able to penetrate between the shaft and motor housing, which allows rust to accumulate. As the rust builds up, the motor is put under stress, as it contends with the rising levels of friction on the shaft to keep the wipers moving, until the point when the increased load is drawing a current greater than 30amps, which is when the wiper motor’s fuse will blow. In addition, should the water that has penetrated between the shaft and housing freeze or the wiper blades freeze to the windscreen and are not freed before the wipers are switched on, the excessive load on the motor may also induce premature failure.

To support garages to encourage drivers to replace their wiper blades, First Line Ltd. has produced a handy poster, outlining key information on when to replace wiper blades, which is on request by filling in the online form here https://mailchi.mp/firstlineltd.co/posters.
